Jetbox 3300-W

etBox 3300-w is a compact-sized embedded Linux computer with low power consumption, designed to fit in small front-end controller system applications. With 16DIO channels in addition to the dual Ethernet, dual USB and dual serial ports, the embedded computers help users to extend the dataset to provide more flexible connection configurations for versatile control applications. Combined with IP31 rugged enclosure, fan-less, anti-vibration/shock design and -40~80oC wide operating temperature range, the JetBox 3300-w ensures the reliability and high performance of front-end controller applications under harsh industrial environments.

Compare Product
Category:

JetBox 3300-w is a compact-sized embedded Linux computer with low power consumption, designed to fit in small front-end controller system applications. With 16DIO channels in addition to the dual Ethernet, dual USB and dual serial ports, the embedded computers help users to extend the dataset to provide more flexible connection configurations for versatile control applications. Combined with IP31 rugged enclosure, fan-less, anti-vibration/shock design and -40~80oC wide operating temperature range, the JetBox 3300-w ensures the reliability and high performance of front-end controller applications under harsh industrial environments.

Embedded Linux Ready
Korenix is devoted to the Linux computing and benefits customers by providing the JetBox series with embedded Linux ready system and easy-to-use interface. Compared to general purpose Linux system, embedded Linux is performance-optimized for front-end industrial control.

RISC-Based Computer with low power consumption
The JetBox 3300 is a RISC-based computer with lower power consumption and is stable and reliable. The JetBox 3300 carries 2 LAN ports, 2 USB ports, 2 Serial ports, and 16 Digital IOs to be the best solution in industrial control.

Digital Input & Output
Digital inputs and outputs are widely used in industrial applications such as indicators, alarms, reed switches, or sensors. The compact JetBox carries as many as 16 DIO channels and works as a front-end control agent.

Embedded Compact 2 LAN & 2 Serial Linux Computer

  • Atmel ARM Processor with low power consumption for reliable performance
  • Embedded Linux ready for easy maintenance
  • Linux SDK for quick time-to-market
  • 2 LAN ports for Daisy-Chain Controller
  • 2 USB for data storage
  • 2 RS232/422/485 and 8DI & 8DO for device and signal control
  • One microSD card slot for customized configurations

Fan-less, ruggedized industrial design for anti-vibration/shock and -40~80 ℃ wide operating temperatur

Hardware Specifications

System
Processor
Atmel ARM AT91RM9200 180 MHz
System Memory
64MB SDRAM
System Flash
16MB ROM
Ethernet
10/100 Base-Tx RJ-45 connector x2
Storage
microSD card slot x1
Serial Port
RS232/422/485 x2 (RJ45 connector)
USB
USB 2.0 full speed x2 (Host)
Supporting devices
USB flash, wireless dongle
Digital IO
DI x8, DO x8
LED on Ethernet port
Link/Activity (Green on/blinking)Fdx/Col status(Yellow on/ blinking)
LED per unit
Power on/off x1 (Green on/off)Ethernet Link/ Activity (Green on/ Green blinking) x2Serial Tx only(Green),Rx only(Red),Both (Orange) x2Reset button x1
HW Watchdog Timer
Generates a time-out system reset, 1 sec.
Power Supply
DC 12~48V
Power Consumption
7.2W
OS support
Embedded Linux 2.6.21
Mechanical
Construction
Sheet metal case
Color
Silver
Mounting
Wall mount/DIN rail
Dimension
109(H) x 88(W) x 27(D) mm
NetWeight
0.5kg
Environment
Operating Temp
-40 ~ 176°F(-40 ~ 80°C), 5 to 95% RH
Storage Temp
-40 ~ 176°F(-40 ~ 80°C), 5 to 95% RH
Regulation
FCC class A, CEEN55022 class AEN55024EN61000-3-2, 3EN61000-4-2, 3, 4, 5, 6, 8, 11
Shock
IEC60068-2-27 (50g peak acceleration)
Vibration
IEC60068-2-6 (5g/10~150Hz/operating)
MTBF
Greater than 200,000 hours@25°C
Software Specifications
Embedded Linux 2.6.21 (JetOS93 lite)
Bootloader

JetBox bootloader

Protocol

ARP, PPP, CHAP, IPv4, PAP, ICMP,
TCP, UDP, NFS

Software packages

busybox (telnetd, inetd, udhcp,
syslogd), diocfg, Irzsz, minicom, microcom, , ncurses,

ser2net, setserial, bridge-utils, ethtool, goahead web server,
iptables, net-snmp, ntp, openssh, openssl, pppd, ftpd, rp-pppoe,
smtpclient, wireless-tools

Interface

Serial Interface

Serial service modes: TCP server

LAN Interface

Ethernet: 10/100 Based-Tx RJ-45 connector x2,
auto MDI/MDI-X

Management and Security
Security: HTTPS, SSHSNMP: MIB and trapsNTP for time management
Device Drivers

microSD card, USB, Watchdog timer, UART, Ethernet
